Unit Dimension: 56 x 32 x 23 mm / 2.2 x 1.26 x 0.91 inch (L*W*H); Voltage: 24V;
Introduction of Open Frame Solenoid:
Linear Open-Frame Solenoids are available in various designs, as Pull, Thrust (Push) or a combination type, which offer a simple and robust action for the industry and automation equipment.
We can make both AC or the DC power sources ; DC Voltage ; 6 V , 12 V ,24 V 36 V ,48 and 60 V . AC Voltage: 110V, 115V & 230V.
Custom AC & DC voltages available on request for your specification.
Long stroke designs for improved performance over greater strokes.
Electric wire fitted 200mm as standard.
Optional return springs or the mounted screw holes.
Fixing arrangement, plunger coupling, thrust rod options and lead length can all be customize
Unit Features:
DC24V Push pull Type, linear motion, frame type, plunger spring return, Low power consumption to ensure high efficiency and 300,000 cycle lifespan.
D Type Frame Solenoid electromagnet has simple structure, small volume, high adsorption force. Good copper coil inside, has good temperature resistant performance along with high electrical conductivity.
Standard working condition: Ambient Temperature: 20±2℃, Relative Humidity: 65±5%RH
Product Standards ● designed and tested to VDE 0580 ● manufactured to ISO 9001
Material Selection:
Solenoid Enclosures : We offers two types of enclosures, each for a variety of applications: a one-piece molded epoxy construction called the Red Hat II solenoid and a conventional Red Hat metallic construction. Both meet ICS-6 ANSI/NEMA, and UL Standards 429, 508, and/or 1002. These standards define enclosure protection levels and the tests passed to earn each Type designation
Application:
The Pull push type, linear motion open frame, plunger spring return, DC solenoid electromagnet of Dr. Solenoid are wildly used in vending machines, transporting equipment, office device; smart household appliance, mechanical used.
Notice: please take the electromagnet put down gently when you install it. The screw thread can make a corresponding change according to your demand. This product is small in size, please pay attention to in the process of using electricity, so as not to damage the electromagnet.
