AS 25040 DC lifting Electromagnet
Product Description
| Brand | Dr. Solenoid | Model Number | AS 25040 |
| Rated Voltage (V) | DC 12V, 18V and 24V | Rated Power(W) | 90 W |
| Work Mode: | Power on, Magnet on | Holding Force (N) | 160 KG |
| working duty | 100% | Resistance | 82 Ω |
| Service Life | 100 Thousand Times | Certification | CE,ROHS,ISO9001, |
| Material | Superior Magnet Carbon Steel Housing | Lead Wire Length(mm) | 200 MM |
| Install Style | Screw Hole | Tolerance of Dimension | +/- 0.1 MM |
| Water-proof | None | Insulation Class | B |
| Hi-Pot Test | AC 600V 50/60Hz 2s | Non-excitation Holding Force | 0 |
| Working Temperature | -10°C-100°C | Duty Cycle | 1-100% |
| Thread Depth(mm) | / | Payment Term | TT, or LC At Sight |
| Sample Order | Yes | Warranty | 1 Year |
| MOQ | 1000 pcs | Supply Ability | 5000 pcs per Week |
| Delivery Time | 30 Days | Port of Loading | shenzhen |
Unit Features：
Size: 250 * 70 *40 mm
DC Power Voltage: DC 9V，12V or 24V
Power Wattage: 90 W
Current: 1.25 A
Resistance: 82 Ω
Suction Force: ≥ 160 Kg
Lifespan cycles: ≥100,000 times
Working duty cycle: 100%ED
Housing: Round magnets is made of high quality carbon steel, with plated Nickle coating, small size for easy storage, strong adsorption, high conductivity, high temperature resistance. RoHS compliance.
Design : Water proof， DC powerful and compact design
Performance； Low consumption，reliable temperature rise, and long lifespan.
Application: In the industrial field, the suction cup electromagnet/solenoid is used to adsorb and carry metal workpieces to improve production efficiency and operational safety. In family, it is used to adsorb various small objects, such as keys, needles, etc., to prevent loss. In scientific research, it is used to demonstrate the attraction of magnetic fields to objects.
Technology: The structure of the suction cup electromagnet is reasonably and compactly designed. The copper coil is placed in a soft magnetic metal material shell and is cast with epoxy. It has the characteristics of small size, large suction force, firm and reliable, fully sealed, and strong environmental adaptability. It can be remotely operated, with simple and sensitive movements and stable and reliable functions. It is suitable for conveying control parts of materials or products on automated production lines, and is also used in manipulators, food machinery, medical machinery, and automated control systems. It can be used to suck and lift cast iron ingots, steel balls, pig iron blocks, machined chips, etc. Almost all special-purpose suction cup electromagnets are available, such as normal temperature type, high temperature type, strong magnetic type, etc.
Advantage :
The electric lifting magnet has a flat and smooth surface, excellent workmanship, good electrical conductivity and insulation, small size and large adsorption force, it is a powerful, compact, low-consumption and reliable quality product。
Cautions for the using :
1.The object absorbed must be a good magnetic material.
2.The suction surface of the electromagnet must be smooth and clean.
3.The thickness of the object is 5mm best.
4.The contact surface of the object must be larger than the adsorption surface of the electromag.
Summary, the suction cup electromagnet is not only an efficient tool, but also plays an important role in many fields. From improving production efficiency to small applications in daily life.
Size: 250 * 70 *40 mm
DC Power Voltage: DC 9V，12V or 24V
Power Wattage: 90 W
Current: 1.25 A
Resistance: 82 Ω
Suction Force: ≥ 160 Kg
Lifespan cycles: ≥100,000 times
Working duty cycle: 100%ED
Housing: Round magnets is made of high quality carbon steel, with plated Nickle coating, small size for easy storage, strong adsorption, high conductivity, high temperature resistance. RoHS compliance.
Design : Water proof， DC powerful and compact design
Performance； Low consumption，reliable temperature rise, and long lifespan.
Application: In the industrial field, the suction cup electromagnet/solenoid is used to adsorb and carry metal workpieces to improve production efficiency and operational safety. In family, it is used to adsorb various small objects, such as keys, needles, etc., to prevent loss. In scientific research, it is used to demonstrate the attraction of magnetic fields to objects.
Technology: The structure of the suction cup electromagnet is reasonably and compactly designed. The copper coil is placed in a soft magnetic metal material shell and is cast with epoxy. It has the characteristics of small size, large suction force, firm and reliable, fully sealed, and strong environmental adaptability. It can be remotely operated, with simple and sensitive movements and stable and reliable functions. It is suitable for conveying control parts of materials or products on automated production lines, and is also used in manipulators, food machinery, medical machinery, and automated control systems. It can be used to suck and lift cast iron ingots, steel balls, pig iron blocks, machined chips, etc. Almost all special-purpose suction cup electromagnets are available, such as normal temperature type, high temperature type, strong magnetic type, etc.
Advantage :
The electric lifting magnet has a flat and smooth surface, excellent workmanship, good electrical conductivity and insulation, small size and large adsorption force, it is a powerful, compact, low-consumption and reliable quality product。
Cautions for the using :
1.The object absorbed must be a good magnetic material.
2.The suction surface of the electromagnet must be smooth and clean.
3.The thickness of the object is 5mm best.
4.The contact surface of the object must be larger than the adsorption surface of the electromag.
Summary, the suction cup electromagnet is not only an efficient tool, but also plays an important role in many fields. From improving production efficiency to small applications in daily life.
Product detail diagram
