AS 2551 DC Solenoid Tubular Type

What is DC Solenoid Tubular Type ?

DC solenoids tubular type can custom the DC voltages between 3-24V and force up from 5 to 50N. The push and pull force can be significantly increased with limited energized time and with connection to big and high voltage. The DC solenoids tubular type is set up with a return spring inside, and are available in various construction types such as open, tubular, self-holding latching bistable and holding magnet designs. All DC solenoids tubular are available in mechanical pull L or push S designs and can be customized per specification. Common customizations like voltage , copper coil,plunger housing are mechanical as well as cable connections and cabling.

Powerful and compact.

Smooth and flat surface.

Low consumption and reliable temperature rise

Ambient temperature within 130 degrees.

Electromagnet in working condition would produce a certain amount of heat, electricity more frequently the higher temperature, which is a normal phenomenon.

product details

Product Description

Brand	Dr. Solenoid	Model Number	AS 2551
Rated Voltage (V)	DC 12V, 18V and 24V	Rated Power(W)	47 W
Work Model	Push and Pull Linear Type	Holding Force (N)	1000 GF
Stroke(mm)	Customized	Reset Time(s)	1 S
Service Life	500 Thousand Times	Certification	CE,ROHS,ISO9001,
Material	Carbon Steel	Lead Wire Length(mm)	200
Install Style	screw	Tolerance of Dimension	+/- 0.1 MM
Water-proof	None	Insulation Class	B
Hi-Pot Test	AC 600V 50/60Hz 2s	Non-excitation Holding Force	0
Working Temperature	-10°C-100°C	Duty Cycle	1-100%
Thread Depth(mm)	/	Payment Term	TT, or LC At Sight
Sample Order	Yes	Warranty	1 Year
MOQ	1000 PCS	Supply Ability	5000 pcs per Week
Delivery Time	30 Days	Port of Loading	shenzhen

Unit Features:

DIMENSION : φ25.4*51.5mm / 1 * 2.02 Inches. Stroke Distance: 10 Mm

Tubular Housing Shell: Stainless steel housing enclosure, high shining and smooth surface, RoHs and Reach compliance.

Plunger: φ10 mm Carbon steel material

Voltage: DC12V 18V and 24 V

Stroke: 4-10 mm ( adjustable )

Force: 1000 Gf

Power: 47 W

Current: 1.74 A

Resistance: 13.8 Ω

Lifespan cycles: ≥200,000 times

Working Cycle: 0.1s On, 1s Of

DESIGN- our solenoids tubular type are especially optimized for long strokes. Solenoids tubular, like other linear solenoids, are on/off type actuators that developing force in one direction when the power on. The return force must be provided externally, via a return strong spring for instance.

Notable Characteristics of Solenoids tubular :

• Stroke up to 20mm (depending on size of the housing ad the type you like )
• Optimized for long strokes
• Holding force up to 5N-- 80N (in end-position, energized)
• Long lifespan expectancy: Up to 30 million+ cycles
• Pull and Push Solenoid tubular versions available
• Custom solenoids available, including latching versions (permanent magnet)

ADVANTAGES- Simple structure, small volume, high adsorption force copper coil inside, has good temperature stability and insulation, high electrical conductivity. Less power consumption, low temperature rise, no magnetism when power off. It can be installed flexibly and quickly, which is very convenient.

APPLICATION : DC Tubular solenoid electromagnet use in vending machines, transport equipment, office facility household appliance, mechanical, etc game machine, Sorting machine, door lock, etc.

NOTED: As an actuating element of animation equipment ,because the current is large, the single cycle can not be electrified for a long time. The best operate time is in 2 seconds.
