Unit Dimension: Diameter 40, High 25 Mm;
The Holding sucker Solenoid Principle
The principle design of holding sucker solenoid is to maintain electromagnetic attraction when the power on. Once the power is off, the electromagnet will lose its attraction and release the object accordingly. The standard model of this holding sucker solenoid has an outer diameter range from 20mm-150mm.
Unit Feature:
Compact and powerful Design
Body Material: High Carbon Steel with Zinc coating. Smooth surface and Rohs Compliance, anticorrosion also.
Power Source: DC 24 V
Peak Force: 300N
Holding Force: 200 N
Duty-cycle: 50%;
Electric time: Less than 7 minutes ;
Electric Lifting Magnet Applications
The Electric Lifting Magnet solenoid are wildly applied to intelligent robots, traditional manipulators for grasping magnetic work pieces, ore sorting machines, and brakes for various rotary mechanisms.
Caution when using the Electric Lifting Magnet solenoid
1.The object should be a well magnetic material.
2. The object surface of the electromagnet should bed smooth.
3. The best thickness of object is better to do with 5 mm..
4. The contacted surface of the object must be bigger or large than the adsorption surface of the electromagnet
We help you make the perfect Electric Lifting Magnet Solenoid
Our R & D team is professionals in the design and manufacture of solenoid. We are always available to listen to your needs and help you find the most suitable solenoid for your project You can also customize your equipment to make it even more practical and versatile, tailored to your objectives. Contact us for a free quote.
