AS 4070 Unlocking the Power of Tubular Pull Solenoids features and application

What is a tubular Solenoid ?

Tubular solenoid comes in two types: push and pull type. A push solenoid operates by pushing the plunger out of the copper coil when power on, while a pull solenoid works by pulling the plunger into the solenoid coil when power is applied.
Pull solenoid is generally more common product, as they tend to have a longer stroke length (the distance the plunger can move) compared to push solenoids. They are often found in applications like door locks, where the solenoid needs to pull a latch into place.
Push solenoids, on the other hand, are typically used in applications where a component needs to be moved away from the solenoid. For example, in a pinball machine, a push solenoid might be used to propel the ball into play.

Unit Features:- DC 12V 60N Force 10mm Pull Type Tube Shape Solenoid Electromagnet

GOOD DESIGN- Push pull Type, linear motion, open frame, plunger spring return, DC solenoid electromagnet. Less power consumption, low temperature rise, no magnetism when power off.

ADVANTAGES:- Simple structure, small volume, high adsorption force.copper coil inside, has good temperature stability and insulation, high electrical conductivity. It can be installed flexibly and quickly, which is very convenient.

NOTED: As an actuating element of equipment ,because the current is large, the single cycle can not be electrified for a long time.The best operate time is in 49 seconds.

product details

Product Description

Brand	Dr. Solenoid	Model Number	AS 4070
Rated Voltage (V)	DC 12V	Rated Power(W)	12 W
Work Model	Tubular Push PULL Type	Holding Force (N)	120 N
Stroke(mm)	6-8 MM	Reset Time(s)	1 S
Service Life	300 Thousand Times	Certification	CE,ROHS,ISO9001,
Material	Carbon Steel Housing with Zinc Plated Coating	Lead Wire Length(mm)	200
Install Style	Adjustable Screw	Tolerance of Dimension	+/- 0.1 MM
Water-proof	None	Insulation Class	F 155 Cel. Degree
Hi-Pot Test	AC 600V 50/60Hz 2s	Non-excitation Holding Force	0
Working Temperature	-10°C-100°C	Duty Cycle	1-100%
Thread Depth(mm)	/	Payment Term	TT, or LC At Sight
Sample Order	Yes	Warranty	1 Year
MOQ	500 pcs	Supply Ability	5000 pcs per Week
Delivery Time	30 Days	Port of Loading	shenzhen

Description:
Push pull Type, linear motion, plunger spring return, DC solenoid electromagnet.
Support DC 12V voltage, high power, pull push type, linear motion, is easy to install.

Specification:
Type: Push Pull Type
Rated Voltage: DC 12V or 24V
Force And Travel: 10mm 60N ; 0mm 120N
Push Bar Dia: 16mm/0.63";
Total Length: 105mm/4.13";
Cable Length: 210mm/8.27";
Size: 40 x 70mm/1.57" x 2.76"(D*L);
Tubular Solenoids application

Tubular solenoid is widely used across a variety of industrial because their reliability, durability, and versatility characteristic. In automotive industry, tubular solenoids are used in power door locks, automatic transmissions, and starter motors. In the healthcare sector, they play a vital role in medical devices such as ventilators and patient beds.

In the realm of industrial automation, tubular solenoid is used in assembly lines, robotic systems, and sorting machines. They has been found in home appliances like washing machines, dishwashers, and refrigerators, where they control water flow and other mechanical wokring operations.
Moreover, tubular solenoid is a critical component in many safety systems. For example, they are used in fire suppression systems, where they control the release of fire-extinguishing substances, and in anti-lock braking systems (ABS) in vehicles, where they modulate brake fluid pressure.

Summery, tubular solenoid is an indispensable part of many modern technologies. Their ability to convert electrical energy into precise mechanical motion makes them a valuable component in a vast array of devices and systems. They are a testament to the power and versatility of electromagnetism, demonstrating how a simple principle can have far-reaching applications.
