Dimension: φ49 *100 mm / 1.93 * 3.94 Inches. Stroke Distance: 13 mm.
Principle of Tubular Solenoid:
Tubular solenoid is the same like the frames and round steel tubes. This is based on the movable iron core,
fixed iron core, electromagnetic coil, etc. inside the electromagnet. When it is plugged in, Finally, a process of pushing or pulling occurs. it is a piston-like movement.
Features:
Tubular Housing: Carbon steel housing enclosure, high shining and smooth surface, Rohs and Reach compliance standard.
Plunger: φ10 mm Carbon steel material
Voltage: DC24 V
Stroke: 8 mm (adjustable according to the requirement)
Force: 3 Kg
Power: 48 W
Current: 1.8 A
Resistance: 13.8 Ω
Lifespan cycles: ≥200,000 strokes
Temperature rise: max 65 degrees . Cel.
Working Cycle: 1 s On, 3s Of
Custom Design :
We are able to customize various types of tubular solenoid at, small push-pull solenoid, and push-pull solenoid. If you have relevant push-pull tubular solenoid like AS 4910 drawings or technical requirements, parameter requirements, processing requirements,, our professional R & D team can make your requirements according to your product application needs. At present, 97% of customers are non-standard customizations, and a small number of customers have conventional products. As for your project and the design, pls contact us with your specification.
