AS 0420 DC Linear Solenoid Actuators Open Frame and Push Pull Type
Product Description
| Brand | Dr. Solenoid | Model Number | AS 0420 |
| Rated Voltage (V) | DC 6V , 12V 18 V or 24V | Rated Power(W) | 11.5-15 W |
| Work Mode | Push and Pull Liear Movement | Holding Force (N) | 2--6N |
| Stroke(mm) | 3-8 MM Customized | Reset Time(s) | 0.5 S On， 1.5 S OFF |
| Service Life | 200 Thousand Times | Certification | CE,ROHS,ISO9001, |
| Material | Superior Magnet Iron | Lead Wire Length(mm) | 200 MM |
| Install Style | Screw | Tolerance of Dimension | +/- 0.1 MM |
| Water-proof | None | Insulation Class | B |
| Hi-Pot Test | AC 600V 50/60Hz 2s | Non-excitation Holding Force | 0 |
| Working Temperature | -10°C-100°C | Duty Cycle | 1-100% |
| Thread Depth(mm) | / | Payment Term | TT, or LC At Sight |
| Sample Order | Yes | Warranty | 1 Year |
| MOQ | 1000 pcs | Supply Ability | 5000 pcs per Week |
| Delivery Time | 30 Days | Port of Loading | shenzhen |
Unit Features:
Size: 20.5*12*11mm
Plunger: φ4--6 mm
Voltage Options: DC 6 V,12V, 18V or 24V
Stroke: 4-8 mm
Force: 2-8 N
Power: 7--12 W
Current: 0.5---0.9 A
Resistance: 60--150 Ω
Life: ≥300,000 times
Working Cycle: Continuous Power
1. Precise push-pull action: it can achieve relatively precise linear motion.
2. Strong force: it can generate strong thrust or pull.
3. Housing : carbon steel housing with Zinc coating, anti corrosion and smooth surface.
4. Reasonable temperature rise and stable performance.
Product detail diagram
