AS 0730 high force push pull solenoid 12V

AS 0730 high force push pull solenoid 12v


Essentially, a solenoid is an electromagnet: it's made of a copper coil wound on a frame housing, with a free-flowing metal frame type housing in the center of the coil. When electricity is powered on, the plunger is pulled toward the center of the solenoid coil. This allows the solenoid to pull ("pull" from one end) or push ("push" from the other end).

This push pull  solenoid is quite nice and has a lot more power for a reasonable size (compared to our small solenoid). It has a 40mm long housing and a fixed frame with a spring (to hold the shaft). This means that the solenoid moves the shaft when 24V is applied, and when there is no pulling force, the return spring returns the shaft to its original position. It is very practical. Many cheap solenoids can only push or pull the shaft and have no armature to hold the shaft (the shaft will fall off the solenoid). Cheap solenoids also have no return spring.



    Contact us Download
    product details

    Product Description

    Brand Dr. Solenoid Model Number AS 0730
    Rated Voltage (V) DC12V  or 24V  Rated Power(W) 15--30W
    Work Mode Push and Pull  Holding Force (N) 2--5 N
    Stroke(mm) 3-6 MM Customized Reset Time(s) 1 S On，3 S OFF
    Service Life 200 Thousand Times Certification CE,ROHS,ISO9001,
    Material Superior Magnet Iron Lead Wire Length(mm) 200 MM
    Install Style Mounting Hole Tolerance of Dimension  +/-  0.1 MM
    Water-proof  None Insulation Class B
    Hi-Pot Test AC 600V 50/60Hz 2s Non-excitation Holding Force 0
    Working Temperature -10°C-100°C Duty Cycle 1-60%
    Thread Depth(mm) 3 mm  Payment Term TT, or LC At Sight
    Sample Order Yes Warranty 1 Year
    MOQ 1000 pcs Supply Ability 5000 pcs per Week
    Delivery Time 30 Days Port of Loading shenzhen

    Product detail diagram

    AS 0730 high force push pull solenoid 12v D 1AS 0730 high force push pull solenoid 12v D 2AS 0730 high force push pull solenoid 12v D 3AS 0730 high force push pull solenoid 12v D 4AS 0730 high force push pull solenoid 12v D 5AS 0730 high force push pull solenoid 12v D 6

    Both advantages and disadvantages of The strong push-pull solenoid 12V

    Advantage

    High force output: They are designed to generate stroke force, making the solenoid suitable for applications that require strong actuation device, such as industrial machinery, automotive device systems, and heavy equipment.

    Fast Response: High strength push-pull solenoids also features with respond quickly, allowing for quick actuation and precise control in applications where speed is critical. This is beneficial in applications such as robotics and automated manufacturing processes.

    Precise Control: These strong push pull solenoids can relatively accurately control the applied force and position of the actuator. This makes them suitable for applications that require precise positioning or force regulation, such as certain medical devices and scientific instruments.

    Compact Design: Despite the high force capabilities, it can be designed into relatively compact packages, which is a great advantage in applications where space is limited. This allows the unit for easy integration into a variety of systems without taking up excessive space.

    Reliability: If properly designed and manufactured, strong push-pull solenoids can have high reliability and long service lifespan. They are often used in critical applications that require consistent performance.

    Disadvantage

    High Power Consumption: To generate high force, these solenoids typically require a significant amount of electrical power. This can lead to high energy consumption and may require additional power - conditioning equipment, increasing the overall cost and complexity of the system.

    Heat Generation: The high power consumption can also result in significant heat generation. This may require additional cooling mechanisms to prevent overheating, which adds to the system's complexity and cost. In some cases, excessive heat can also affect the performance and lifespan of the solenoid and other components in the vicinity.

    Electromagnetic Interference: Solenoids can generate electromagnetic interference (EMI), which may affect the operation of nearby electronic devices. This requires proper shielding and filtering to minimize the impact on other components in the system.

    Limited Stroke Length: While they can produce high force, the stroke length of high - force push - pull solenoids is often relatively limited compared to some other types of actuators. This may restrict their use in applications that require a long - distance movement.

    Cost: High - force solenoids are generally more expensive than standard - force solenoids due to their specialized design and manufacturing requirements. This higher cost can be a limiting factor in some applications, especially those with budget constraints.

    FAQ:
    Q: Are you a trading company or manufacturer? And where is your factory located?
    A: We are the professional solenoid and solenoid valve factory with 20 years’ experience. Our factory is located in Dongguan City, 1 hours from Shenzhen or Guangzhou Airport by car.

    Q: Do you have any certification approved?
    A: For the certification, it depends on the product. Some we have CE along with Rohs.

    Some Custom dsign, we can help and get third part approval.

    Q: How to choose a suitable high force push pull solenoid quickly?
    A: Please provided us the follow specification that meet your project requirement.:
      Act form: pull or push type?
      Frame type or tubular type?
     Stroke Distance ?
     Push force ?

    Duty cycle, time for action and time for release
    lead wire length and the type connector,
    -------------------------------
    For example: You can mention that I want purchase open frame solenoid as below:
    Open frame type solenoid
    Action Form: Pull type
    Housing Size: L37xW26xH20
    Stroke Distance : 10 mm
    Pull Force: 1 N
    DC Power Voltage:       DC 12V,2A
    Duty Cycle:  10%, Energized time: 6S, de-energized time: 60s
    Lead Wire:   side out 10 cm, with XH2.54 male connector.
    Install Thread size: M3
    ---------------------------------------
    Q: How long is your delivery time for the sample and the production time ?
    A: If we have sample in hands, Samples ready for delivery in 3 days or in 10-20 days for  customized product. It is according to quantity. Normally, you will get our samples in 7-10 days after payment.

    Q: Can you customized the solenoid product as Customer design ?
    A: Yes, you are welcome.

    Q: Can I print my Brand/Logo on the product?
    A: Yes, we can help and do the logo on the housing
